    DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
      • DXP16N-C-H Mobile Phone Miniature SPEAKER
    Product Details

     DXP16N-C-H.pdf DOWNLOAD








    ModelDXP16N-C-H
    Rated Impedance8 ohm
    Rated Power0.8w
    Max Power1.0w
    Resonance Frequency（Fo）550 HZ
    Rated Freq. RangeFo-20kHz
    Sound Pressure Level90±3dB/0.1W/0.1
    Magnet NdFeB
