    DXP17N-A-H Mobile Phone Miniature SPEAKER
      • DXP17N-A-H Mobile Phone Miniature SPEAKER
      • DXP17N-A-H Mobile Phone Miniature SPEAKER
      • DXP17N-A-H Mobile Phone Miniature SPEAKER
      • DXP17N-A-H Mobile Phone Miniature SPEAKER
      • DXP17N-A-H Mobile Phone Miniature SPEAKER
    Product Details

     DXP17N-A-H.pdf DOWNLOAD





    ModelDXP17N-A-H
    Rated Impedance8 ohm
    Rated Power0.5w
    Max Power0.8w
    Resonance Frequency（Fo）800 HZ
    Rated Freq. RangeFo-5000 Hz
    Sound Pressure Level92±3dB/0.1W/0.1
    Magnet NdFeB
