    DXP18N-B-H Mobile Phone Miniature SPEAKER
      • DXP18N-B-H Mobile Phone Miniature SPEAKER
      • DXP18N-B-H Mobile Phone Miniature SPEAKER
      • DXP18N-B-H Mobile Phone Miniature SPEAKER
      • DXP18N-B-H Mobile Phone Miniature SPEAKER
      • DXP18N-B-H Mobile Phone Miniature SPEAKER
    Product Details

    DXP18N-B-H.pdf DOWNLOAD





    ModelDXP18N-B-H
    Rated Impedance8 ohm
    Rated Power0.8w
    Max Power1.0 w
    Resonance Frequency（Fo）1000 HZ
    Rated Freq. RangeFo-20K Hz
    Sound Pressure Level91±3dB/0.1W/0.1
    Magnet NdFeB
