Resonant Frequency (KHz) | 4.0 ±0.5 |
Operating Voltage (Vp-p) | 1.0~30.0 |
Rated Voltage (Vp-p) | 5.0 |
Sound Pressure Level (dB/min) | 70 at 10cm at 3Vp-p Square Wave 78 at 10cm at 5Vp-p Square Wave |
Capacitance (pF) | 12000 ± 30﹪ at 1kHz |
Operating Temperature (℃) | -40 ~ +85 |
Storage Temperature (℃) | -40 ~ +85 |
Condition by wave (℃) | 255±5℃ / within 3sec |
Condition by hand (℃) | 350±10℃ / within 3sec |
